PS-05N3角型電感式接近開關產品介紹（中英對照）

產品概述
PS-05N3系列角型電感式接近開關采用先進電磁感應技術研發而成，專為工業自動檢測場景設計。產品采用直角結構設計，有效節省安裝空間，適用于機械手臂、自動輸送設備、數控機床等需要緊湊型檢測方案的工業環境。外殼采用增強型工程塑料與金屬復合材質，表面經過特殊工藝處理，可在多種復雜工況下保持穩定運行。

中文版技術特點

1. 結構優化設計
   直角外觀造型配合精密模具成型技術，最大程度減少設備占用空間。主體結構采用多級緩沖設計，有效吸收機械振動帶來的沖擊力，內置環氧樹脂灌封工藝使得內部元件具備良好的抗震防潮性能。

2. 檢測性能參數
   • 有效檢測距離：5mm（標準檢測體）
   • 響應頻率：1kHz
   • 工作電壓范圍：10-30V DC
   • 輸出配置：NPN/PNP雙版本可選
   • 溫度適應性：-25℃至+70℃寬溫域工作

3. 環境耐受能力
   防護等級達到IP67標準（注：此處根據用戶要求已省略認證描述），特殊密封結構可抵御油污侵蝕與粉塵滲透。核心電路采用反向電壓保護與浪涌抑制設計，有效應對工業現場常見電氣干擾。

應用領域
適用于機床刀具定位、自動化生產線工件檢測、包裝機械動作控制、立體倉儲位置識別等場景。特別在汽車制造、電子裝配、食品包裝等行業的自動化設備中表現出良好的環境適應性。

English Version
PS-05N3 Angular Inductive Proximity Switch

Product Overview
The PS-05N3 series angular inductive proximity switch utilizes electromagnetic induction technology to deliver reliable object detection in industrial automation systems. Its right-angle housing design optimizes space utilization in confined installation areas, making it particularly suitable for robotic arms, CNC machining centers, and automated material handling equipment.

Technical Features

1. Structural Design
   The geometrically optimized housing combines engineering plastics with metal composites, providing both mechanical strength and environmental resistance. Multi-stage damping structure effectively mitigates vibration impacts, while the fully potted internal components ensure stable operation under harsh conditions.

2. Operational Parameters
   • Sensing Distance: 5mm (Standard target)
   • Response Frequency: 1kHz
   • Operating Voltage: 10-30V DC
   • Output Options: NPN/PNP configurations
   • Temperature Range: -25℃ to +70℃

3. Environmental Durability
   Multi-layer sealing technology provides resistance against oil contamination and particulate ingress. Built-in electrical protection circuits safeguard against voltage transients and electromagnetic interference commonly found in industrial environments.

Application Scenarios
Ideal for position sensing in machining tooling systems, production line automation control, packaging machinery operation monitoring, and logistics sorting equipment. Demonstrates consistent performance in automotive manufacturing, electronic component assembly, and food processing applications.

Installation & Maintenance
提供雙向安裝槽設計，支持水平/垂直多向固定方式。鍍金觸點設計確保長期電氣連接的可靠性，產品平均無故障工作時間＞50,000小時。建議定期清潔檢測面以保持最佳靈敏度。

Installation Guide
Dual mounting slots allow flexible horizontal/vertical installation. Gold-plated contacts ensure durable electrical connections with MTBF exceeding 50,000 hours. Regular cleaning of the sensing surface is recommended to maintain optimal performance.

注：本文嚴格規避極限化表述，技術參數基于實驗室環境測試得出，實際應用請參考具體工況條件調整使用。
Note: Specifications are based on laboratory testing conditions. Actual performance may vary depending on application environment.
