角型電感式接近開關SN04-D1 價格
產品概述
SN04-D1角型電感式接近開關是一款采用非接觸式檢測技術的工業級傳感器，專為金屬物體檢測設計。該產品具有方形外觀結構，尺寸緊湊（181835mm），適合在空間受限的安裝環境中使用。其核心采用電磁感應原理，能夠穩定檢測鐵、鋼、銅等導電金屬材料，檢測距離為4mm±10%，響應頻率高達800Hz，可滿足高速自動化生產線的需求。產品外殼采用PBT工程塑料，具備IP67防護等級，能適應-25℃至70℃的工作環境，在粉塵、油污等工業場景中表現可靠。1822
技術特點
該開關提供多種接線方式（NPN/PNP常開/常閉），支持DC10-30V寬電壓輸入，內置浪涌保護、逆極性保護和短路保護功能。獨特的設計使其具備抗電磁干擾能力，殘留電壓≤2.5V，消耗電流≤10mA，負載電流可達200mA。產品采用埋入式/非埋入式兩種安裝方式，通過黃色LED指示燈直觀顯示工作狀態。特別優化的電路設計使開關具備≤3%的重復誤差和1-20%的遲滯范圍，確保在連續作業中保持穩定的檢測精度。電纜標配2米PVC護套線，便于現場布線安裝。2327
應用場景
SN04-D1廣泛應用于機械制造、紡織設備、包裝機械等領域的定位檢測、計數控制和安全防護。在自動化生產線中，可用于檢測傳送帶上的金屬工件、監控機械臂末端位置；在數控機床上，可實現刀具極限位置保護；在物流分揀系統里，能準確識別金屬托盤。其非接觸式工作原理避免了傳統機械開關的磨損問題，特別適用于高頻次、高精度的工業自動化場景。產品還可與PLC、變頻器、伺服控制器等設備直接配合使用，構建完整的控制系統。921
Product Introduction
The SN04-D1 rectangular inductive proximity switch is an industrial-grade sensor designed for non-contact detection of metallic objects. Featuring a compact square housing (181835mm), it employs electromagnetic induction technology to reliably detect ferrous and non-ferrous metals with a sensing range of 4mm±10%. The switch operates at a high response frequency of 800Hz, making it suitable for high-speed automation applications. Its PBT plastic enclosure provides IP67 protection against dust and moisture, with an operational temperature range from -25°C to 70°C. The product offers multiple output configurations including NPN/PNP NO/NC models. 1824
Key Features
This proximity sensor supports 10-30VDC wide voltage input and incorporates built-in protection against reverse polarity, surge currents, and short circuits. With ≤3% repeat accuracy and 1-20% hysteresis, it ensures consistent performance in demanding environments. The device features a yellow status LED, ≤2.5V residual voltage, and ≤10mA current consumption while delivering up to 200mA load capacity. Standard models include 2-meter PVC cables for easy installation, available in flush or non-flush mounting styles. The optimized electromagnetic design provides excellent noise immunity for stable operation near motors or frequency converters. 2228
Typical Applications
Ideal for industrial automation systems, the SN04-D1 excels in position sensing, object counting, and safety interlocking applications. Common uses include metal workpiece detection on conveyor lines, end-of-arm tooling positioning in robotics, and pallet recognition in logistics sorting systems. Its wear-free operation makes it particularly suitable for high-cycle applications like CNC machine tool limit protection, packaging equipment synchronization, and textile machinery control. The sensor can interface directly with PLCs, servo drives, and other control devices to form complete monitoring solutions. 721
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
