薄膜鉑熱電阻WZPK-534U 價格
以下是薄膜鉑熱電阻 WZPK-534U 的中英文產品介紹：
中文介紹
薄膜鉑熱電阻 WZPK-534U 是一種高性能的溫度傳感器，廣泛應用于工業自動化、化工、制藥、電力等領域。該產品采用先進的薄膜鉑電阻測溫元件，具有精確、靈敏、熱響應時間快的特點，能夠快速準確地測量溫度變化。其測溫范圍為 -79℃至 420℃，精度等級為 B 級，熱響應時間 T0.5U ≤5。
WZPK-534U 的外保護管采用 1Cr18Ni9Ti 不銹鋼材質，內部填充高密度氧化物質緣體，具備很強的抗污染能力和優良的機械強度，適合在環境惡劣的場合使用。此外，該產品直徑為 φ4，長度有多種規格可供選擇，安裝固定裝置為可動卡套法蘭。其價格因規格、配置及市場供需等因素而有所不同，具體價格需根據實際需求與供應商協商。
English Introduction
The WZPK-534U thin-film platinum resistance thermometer is a high-performance temperature sensor, widely used in industrial automation, chemical, pharmaceutical, power and other fields. This product uses advanced thin-film platinum resistance temperature measuring elements, which are characterized by accuracy, sensitivity and fast thermal response time, and can quickly and accurately measure temperature changes. Its temperature measuring range is -79℃ to 420℃, with a precision grade of B and a thermal response time T0.5U ≤5.
The outer protective tube of the WZPK-534U is made of 1Cr18Ni9Ti stainless steel, and the interior is filled with high-density oxide insulating material. It has strong anti-pollution ability and excellent mechanical strength, making it suitable for use in harsh environments. In addition, the product has a diameter of φ4 and is available in various lengths to meet different requirements. The installation fixing device is a movable flange with a clamp. The price of the WZPK-534U varies depending on specifications, configurations and market supply and demand. The specific price needs to be negotiated with the supplier according to actual requirements.
薄膜鉑熱電阻
WZP2-236SB，WZP-1312AB，WZP2-1312AB，WZP-212AB，WZP2-212AB，WZP-3312AB，WZP2-3312AB，WZP-4312AB，WZP2-4312AB，WZP-6312AB，WZPK-103U，WZPK-104U，WZPK-105U，WZPK-106U，WZPK-106U，WZPK-204U，WZPK-205U，WZPK-206U，WZPK-303U，WZPK-304U，WZPK-305U，WZPK-306U，WZPK-403U，WZPK-404U，WZPK-405U，WZPK-406U，WZPK-503U，WZPK-504U，WZPK-505U，WZPK-506U，WZPK-133U，WZPK-134U，WZPK-135U，WZPK-136U，WZPK-233U，WZPK-234U，WZPK-235U，WZPK-236U，WZPK-333U，WZPK-334U，WZPK-335U，WZPK-336U，WZPK-433U，WZPK-434U，WZPK-435U，WZPK-436U，WZPK-533U，WZPK-534U，WZPK-535U，WZPK-536U，WZPK-123UWZPK-124U，
簡介
工業用薄膜鉑熱電阻作為新一代的溫度測量和調節傳感器，通常用來和顯示儀表等配套，以直接測量各種生產過程中-79℃～600℃范圍內液體，蒸汽和氣體介質及固定表面等溫度。
技術參數
熱電阻感溫元件在0℃的電阻值（R0）
分度號Pt100 B級 R0=100±0.12Ω
鉑熱電阻的電阻與溫度關系一般可用以下關系表示：在-79～0℃范圍內
Rt=R0｛1+At+Bt2+C(t-100℃)t3｝
Rt=R0(1+At+Bt2)
Rt 為t℃時熱電阻的電阻值（Ω）
式中的R0為0℃時熱電阻的電阻值（Ω）
t為被測介質溫度（℃）
A、B、C等均為有關的分度常數
測量范圍和準確度
|
