電站測溫用熱電阻WZP-621B 價格
產品概述
電站測溫用熱電阻WZP-621B是一款專為電力行業設計的溫度測量設備，適用于火力發電機組、蒸汽管道及鍋爐等高溫高壓環境的溫度監測。該產品采用鉑電阻元件（Pt100）作為核心感溫部件，具有較寬的溫度測量范圍（-200℃至500℃）和良好的穩定性，能夠滿足電站復雜工況下的長期可靠運行需求。其結構設計包含耐腐蝕保護管和抗震接線盒，可適應不同安裝場景的機械強度要求。56
核心特點
WZP-621B熱電阻采用兩節式分離結構設計，保護管與感溫元件可獨立更換，顯著降低了維護成本。感溫元件采用鎧裝化工藝結合彈性壓緊技術，使熱響應時間縮短至行業較優水平，能快速捕捉溫度變化。產品符合電力行業通用技術規范，參考國際通用的EBASCO規格設計，適用于30萬至60萬千瓦發電機組配套使用。其A級精度版本在0℃時電阻值偏差不超過±0.06Ω，B級版本偏差控制在±0.12Ω范圍內，確保測量數據的準確性。210
應用場景
該產品主要應用于火力發電廠中鍋爐汽包、蒸汽管道、煙道風道等關鍵部位的溫度監測，同時也可用于石化、冶金等行業的高溫設備測溫。特殊設計的保護管材料（如1Cr18Ni9Ti不銹鋼）能承受≤9.8MPa的公稱壓力，在介質流速≤100m/s的工況下保持穩定性能。針對軸承溫度測量等特殊場景，產品還提供帶避震結構的變體型號，可直接貼合被測表面實現精確測溫。813
產品優勢
WZP-621B通過優化結構設計實現了安裝便捷性和維護便利性，用戶可將保護管焊接固定后單獨更換感溫元件。相較于同類產品，其鎧裝元件具有更好的抗振動性能和更長的使用壽命，常溫絕緣電阻≥100MΩ（測試電壓10-100V DC）。產品提供單支和雙支兩種配置選項，雙支型號可同時輸出兩組測溫信號，為系統冗余設計提供便利。配套使用的顯示儀表或控制系統無需特殊適配即可直接讀取標準電阻信號。1421
Product Introduction (English)
The WZP-621B thermal resistor is specifically engineered for temperature measurement in power plant applications, including boilers, steam pipelines and turbine systems. Utilizing platinum resistance elements (Pt100) with a measuring range of -200°C to 500°C, it delivers stable performance under high-pressure and high-vibration conditions common in thermal power generation environments. The separable protection tube design allows independent replacement of sensing components, significantly reducing maintenance downtime. 619
Key Features
This product features armored sensing elements with spring-loaded contacts for improved vibration resistance and faster thermal response. The corrosion-resistant protection tubes (available in 1Cr18Ni9Ti steel) withstand working pressures up to 9.8MPa and medium velocities under 100m/s. Its dual-compartment junction box provides IP65 protection level, suitable for outdoor installation. The A-grade version maintains resistance accuracy within ±0.06Ω at 0°C while the B-grade version stays within ±0.12Ω, ensuring reliable temperature monitoring for critical power generation equipment. 215
Typical Applications
Widely implemented in coal-fired power plants for monitoring bearing temperatures, steam headers and flue gas ducts, the WZP-621B also serves well in petrochemical and metallurgical processes. Specialized versions with vibration-damping structures can directly mount on rotating machinery surfaces. The modular design allows flexible configuration with either single or dual sensing elements, the latter providing redundant measurement channels for safety-critical systems. Standard Pt100 output ensures compatibility with most control systems without additional signal conditioning. 1016
Operational Benefits
With a maintenance-friendly design, the protective sleeve can be permanently welded to pipelines while the sensing cartridge remains replaceable. The product s optimized thermal mass enables quicker response to temperature fluctuations compared to conventional designs. Electrical isolation exceeding 100MΩ at 500V DC prevents signal interference in electrically noisy environments. Optional terminal configurations accommodate various cable connection methods, simplifying field installation procedures across different plant environments. 1421
電站測溫用熱電阻
WZC-130B，WZP-220B，WZP-221B，WZP-230B，WZP-231B，WZP2-220B，WZP2-221B，WZP2-230B，WZP2-231B，WZP-220AB，WZP2-220AB。WZC-220B，WZC-230B，WZC-220AB，WZP-320B，WZP-321B，WZP-330B，WZP-331B，WZP2-320B，WZP2-321B，WZP2-330B，WZP2-330B，WZC-320B，WZC-320B，WZP-420B，WZP-421B，WZP-430B，WZP-431B，WZP2-420B，WZP2-421B，WZP2-430B，WZP2-431B，WZP-42AB，WZP2-42AB，WZC-420B，WZC-430B，WZP-420B，WZP-421B，WZP-430B，WZP-430B，WZP-431B，WZP2-420B，WZP2-421B，WZP2-430B，WZP2-431B，WZP-42AB，WZP2-42AB，WZP-420B，WZC-430B，WZP-621B，WZP-621AB，WZP-631B，WZP2 -621B，WZP2 -621B，WZP2 -631B，WZP-621B，WZP-631B，WZP-621B，WZP2 -631B，WZP-621AB，WZP2-621AB，WZP-002，WZP-003，WZP-003A，WZCM-201，WZPM-201，WZPM-201，WZP-270S，WZP-26S，WZP-236SB，
量程規格
名 稱 分度號 測溫范圍 ℃ 精度等級 允 差Δt
鎳鉻－鎳硅熱電偶 K 0～800 2 ±2.5℃或 ±0.75％t
鎳鉻－銅鎳熱電偶 E 0～600 2 ±2.5℃或 ±0.75％t
鉑熱電阻 Pt100 -200～500 B ±（0.3＋0.005|t|）
注：t為感溫元件實測溫度或?qū)崪y(cè)溫度的值。
□公稱壓力
一般是指在常溫下，保護管所能承受的靜態外壓而不破裂，試驗壓力一般采用公稱壓力的1.5倍。實際上，允許工作壓力不僅與保護管材料、直徑、壁厚有關，而且還與其結構形式、安裝方法、置入深度以及被測介質的流速、種類有關。
□熱電偶絕緣電阻
常溫絕緣電阻的試驗電壓為直流500Ｖ。測量常溫絕緣電阻的大氣條件為：溫度15～35℃，相對濕度45％RH，大氣壓力86～106kPa。
對于長度超過1米的熱電偶，它的常溫絕緣電阻值與其長度的乘積應不小于100MΩ•m，
即：Rr•L＞100MΩ•mL＞1m
式中：Rr-熱電偶的常溫絕緣電阻值，MΩ；
L－熱電偶的長度，m。
對于長度等于或不足1米的熱電偶，它的常溫絕緣電阻值應不小于100MΩ。
□熱電阻絕緣電阻
常溫絕緣電阻的試驗電壓可取直流10～100Ｖ任意值，環境溫度應在15～35℃范圍內，相對濕度應不大于80％RH，常溫絕緣電阻值應不小于100MΩ。
□熱電阻允許通過電流
通過鉑電阻的測量電流大不超過5mＡ。
|
