鎧裝鉑電阻WZPK2-136SA 廠家
中文介紹
鎧裝鉑電阻WZPK2-136SA是一種高性能的溫度傳感器，廣泛應用于工業測溫領域。它采用鎧裝結構設計，具有直徑小、易彎曲、抗震性好等特點，特別適合安裝在裝配式鉑電阻無法安裝的復雜場合。該產品的測溫范圍為-200℃至500℃，能夠滿足多種惡劣環境下的溫度測量需求。其熱響應時間短，熱響應時間T0.5S≤12秒，能夠快速準確地反映溫度變化。此外，該產品采用1Cr18Ni9Ti不銹鋼作為保護管和固定裝置材料，具有良好的耐腐蝕性和機械強度。
English Introduction
The WZPK2-136SA armored platinum resistance thermometer is a high-performance temperature sensor widely used in industrial temperature measurement. It features an armored structure design, which makes it small in diameter, easy to bend, and highly resistant to vibration. These characteristics make it particularly suitable for installation in complex environments where conventional platinum resistance thermometers cannot be installed. The thermometer has a wide temperature measurement range of -200℃ to 500℃, making it capable of meeting the temperature measurement requirements in various harsh environments. With a short thermal response time (T0.5S≤12 seconds), it can quickly and accurately reflect temperature changes. Additionally, the product uses 1Cr18Ni9Ti stainless steel for the protective tube and fixing device, offering excellent corrosion resistance and mechanical strength.
鎧裝鉑電阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，鎧裝鉑電阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
鎧裝鉑電阻是一種溫度傳感器，它比裝配式鉑電阻直徑小，易彎曲，抗震性好，適宜安裝在裝配式鉑電阻無法安裝的場合。本公司生產的WZPK系列鎧裝鉑電阻采用引進鉑電阻測溫元件，因此，具有精確、靈敏、熱響應時間快、質量穩定、使用壽命長等特點。
特點
★ 熱響應時間短，減小動態誤差
★ 直徑小，長度不受限制
★ 測量精確度高
★ 進口薄膜電阻元件，性能可靠穩定
工作原理
鎧裝鉑電阻是利用物質在溫度變化時，其電阻值也隨著發生變化的特征來測量溫度的，當阻值變
化時，工作儀表便顯示出阻值所對應的溫度值。
|
