鎧裝鉑電阻WZPK-324S 廠家
產品概述
鎧裝鉑電阻WZPK-324S是一種高精度溫度傳感器，采用先進的設計理念和制造工藝，具有優異的性能和可靠性。該產品廣泛應用于工業過程控制、環境監測、科學實驗等領域，能夠精確測量-200℃至500℃范圍內的溫度變化。相比傳統裝配式鉑電阻，WZPK-324S體積更小、柔韌性更好，可輕松安裝于空間受限或需要快速響應的場合。其獨特的結構設計使其具備出色的抗震性能和機械強度，適合在各種復雜工況下穩定工作。314
產品特點
WZPK-324S鎧裝鉑電阻采用不銹鋼外保護管和高密度氧化絕緣材料內芯結構，既保證了良好的抗污染性能，又確保了產品的耐用性。該產品響應速度快，能夠快速捕捉溫度變化，減小動態誤差；測量精度高，可提供準確可靠的溫度數據。產品采用模塊化設計，直徑從φ3mm到φ6mm可選，長度可根據客戶需求定制，適應不同安裝環境的要求。此外，該產品的可彎曲特性使其能夠適應復雜管道的安裝需求，為特殊場合的溫度測量提供了便利的解決方案。17
技術優勢
WZPK-324S采用優質進口薄膜電阻元件，確保了溫度測量的穩定性和一致性。產品具有熱惰性小、反應迅速的特點，相比普通鉑電阻能更快地反映溫度變化。其獨特的鎧裝結構提供了優異的耐振動和抗沖擊性能，延長了產品使用壽命。該產品支持多種安裝方式，包括固定卡套螺紋、可動卡套螺紋等，方便用戶選擇最適合的安裝方案。同時，產品可直接通過銅導線與二次儀表連接使用，簡化了系統集成過程。1021
應用領域
WZPK-324S鎧裝鉑電阻適用于環保、食品加工、化工、石油、電氣等多個行業的溫度測量需求。在污水處理系統、食品生產線、化工反應釜、石油儲罐等場合都有成功應用案例。產品良好的電輸出特性使其能夠與各類顯示儀表、記錄儀、調節器、數據記錄儀及計算機系統兼容，為工業自動化控制提供精確的溫度輸入信號。在惡劣環境條件下，該產品仍能保持穩定的工作性能，是工業溫度測量的理想選擇。215
Product Introduction
The WZPK-324S armored platinum resistance thermometer is a precision temperature sensor designed for industrial applications. With a compact and flexible structure, it outperforms conventional assembled platinum resistors in installation flexibility and response speed. The product features a stainless steel protective sheath filled with high-density oxide insulation material, ensuring excellent resistance to contamination and mechanical durability. Its small diameter and customizable length make it suitable for various installation scenarios, including confined spaces and complex piping systems.13
Key Features
The WZPK-324S stands out with its fast thermal response, significantly reducing dynamic measurement errors. The imported thin-film resistive element guarantees measurement accuracy and long-term stability. The armored construction provides superior vibration resistance and impact protection compared to standard platinum resistance thermometers. Available in multiple diameters (from φ3mm to φ6mm), the product supports different installation methods like fixed sleeve threads and movable sleeve threads, offering flexibility for diverse application requirements. Its bendable nature allows easy installation in challenging locations.714
Technical Advantages
This temperature sensor demonstrates outstanding performance in harsh environments, maintaining measurement stability under various industrial conditions. The optimized design ensures minimal thermal inertia for quick response to temperature changes. The product s robust construction enhances its service life while maintaining precise temperature readings. Compatible with standard copper connecting wires, it can be directly integrated with most secondary instruments and control systems. The WZPK-324S provides reliable temperature data for process control and monitoring systems across different industries.1021
Application Scenarios
The WZPK-324S finds wide applications in environmental protection, food processing, chemical engineering, petroleum, and electrical industries. It performs exceptionally well in monitoring temperatures in wastewater treatment systems, food production lines, chemical reactors, and oil storage tanks. The product s stable electrical output characteristics allow seamless connection with various display instruments, recorders, regulators, and computer systems. Its ability to maintain performance under demanding conditions makes it a preferred choice for industrial temperature measurement tasks requiring both accuracy and reliability.215
鎧裝鉑電阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，鎧裝鉑電阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
鎧裝鉑電阻是一種溫度傳感器，它比裝配式鉑電阻直徑小，易彎曲，抗震性好，適宜安裝在裝配式鉑電阻無法安裝的場合。本公司生產的WZPK系列鎧裝鉑電阻采用引進鉑電阻測溫元件，因此，具有精確、靈敏、熱響應時間快、質量穩定、使用壽命長等特點。
特點
★ 熱響應時間短，減小動態誤差
★ 直徑小，長度不受限制
★ 測量精確度高
★ 進口薄膜電阻元件，性能可靠穩定
工作原理
鎧裝鉑電阻是利用物質在溫度變化時，其電阻值也隨著發生變化的特征來測量溫度的，當阻值變
化時，工作儀表便顯示出阻值所對應的溫度值。
|
