熱電偶配件WZP-014S 廠家
WZP-014S鉑熱電阻元件產品概述
WZP-014S鉑熱電阻元件是一種采用微型陶瓷管作為保護管的內繞結構溫度傳感器，最小外徑可做到φ1.6mm，適合制成微型探頭。該產品基于鉑電阻隨溫度變化的特性設計，測溫范圍覆蓋-200℃至800℃，具有電氣性能穩定、溫度與電阻關系近線性、精度高等特點。元件可搭配金屬保護管及螺紋接頭、法蘭等安裝件組成裝配式熱電阻，或用于表面測溫場景。其緊湊結構和快速熱響應特性使其廣泛應用于石油、化工、冶金、電力等領域。2719
Introduction to WZP-014S Platinum Thermal Resistor Element
The WZP-014S platinum thermal resistor element features a compact internal winding structure with a miniature ceramic protection tube, enabling a minimal outer diameter of φ1.6mm for micro-probe applications. Utilizing the principle of platinum resistance variation with temperature, it operates within -200℃ to 800℃, offering stable electrical performance, near-linear temperature-resistance correlation, and high accuracy. The element can be combined with metal protective tubes and mounting fixtures (e.g., threaded connectors, flanges) to form assembled thermometers or adapted for surface temperature measurement. Its small size and rapid thermal response make it suitable for industries such as petrochemicals, metallurgy, and power generation.221
產品技術特點
WZP-014S采用陶瓷或不銹鋼套管材質，熱響應時間T0.5≤0.5秒，自熱影響低于0.3℃（5mA電流下）。元件支持三線制接線以減少引線電阻誤差，并與顯示儀、記錄儀等設備配套使用。其結構設計兼顧耐振性與機械強度，適用于防震場合如軸承溫度監測。通過優化繞線工藝和材料選擇，產品在高溫環境下仍能保持穩定性，且可定制端面或鎧裝型號以滿足不同安裝需求。71625
Technical Features
The WZP-014S employs ceramic or stainless steel sheaths with a thermal response time T0.5≤0.5 seconds and self-heating effects below 0.3℃ (at 5mA). Its three-wire connection minimizes lead resistance errors and is compatible with displays and data loggers. The vibration-resistant design enhances durability in high-motion environments like bearing temperature monitoring. Optimized winding techniques and material selection ensure stability under extreme temperatures, while customizable end-face or armored versions adapt to diverse installation conditions.111719
應用場景
該元件適用于需高精度溫度控制的工業場景，如反應釜內介質測溫、管道表面溫度監測、汽輪機推力瓦測溫等。在食品、紡織、醫藥等行業中，其衛生型結構設計符合生產環境要求。此外，微型化特性使其在科研儀器和狹小空間部署中表現突出。21220
Application Scenarios
Ideal for high-precision industrial temperature control, the element is used in reactor medium measurement, pipeline surface monitoring, and turbine thrust pad applications. Its hygienic design meets requirements in food, textile, and pharmaceutical industries, while the miniaturized version excels in scientific instruments and confined spaces.51423
