防水式接線盒WZP-231 供應
產品概述
防水式接線盒WZP-231是一款專為工業環境設計的溫度傳感器保護裝置，采用固定螺紋連接方式，配備防水結構，適用于石油、化工、食品制藥等領域的溫度測量場景。該產品可與顯示儀表、記錄儀及電子調節器配套使用，實現對液體、蒸汽、氣體介質及固體表面溫度的穩定監測，測量范圍覆蓋-200℃至420℃。外殼采用不銹鋼材質，兼具機械強度與耐腐蝕性，內部接線盒設計符合防水要求，能在多塵、潮濕等復雜環境中保持可靠性能。41119
核心特點
WZP-231的核心優勢體現在其結構設計與功能性上。產品采用雙層密封結構，接線盒部分通過曲路密封和緊固件組合實現防塵防水，防護等級滿足工業場景需求；感溫元件選用鉑電阻材料，溫度響應時間短（T0.5≤40S），測量精度高，長期穩定性好。保護管直徑提供12mm標準規格，插深可根據需求定制（75-1200mm），安裝方式支持固定螺紋式，便于現場部署。此外，雙支型號（WZP2-231）可同步輸出兩組信號，滿足多儀表協同監測需求。4514
技術參數
產品技術性能包括：測量電流5mA時自熱影響≤0.30℃；常溫絕緣電阻≥100MΩ（測試電壓10-100VDC）；公稱壓力6MPa（常溫靜態）。感溫元件采用鉑絲繞組均勻繞制在絕緣骨架上，確保溫度梯度測量的準確性。接線盒提供防水端子連接，支持三線制或四線制接線方式，適配多種工業控制系統。保護管材質可選304、316L等不銹鋼，適用于酸堿腐蝕環境。產品設計符合工業設備緊湊安裝要求，總長度和置入深度可靈活定制。111822
應用場景
該產品廣泛應用于工業流程控制領域，特別適合發電廠蒸汽管道、化工廠反應釜、食品加工生產線等需要防水防塵的測溫場景。在石油儲罐、碼頭輸油管道等戶外設施中，其防水結構能有效應對雨水侵蝕；制藥潔凈廠房則利用其密封性避免污染物侵入。產品亦常用于高溫高壓設備如合成塔、鍋爐的溫度監控，不銹鋼外殼可耐受高溫介質沖刷。針對不同介質特性，用戶可選擇單支或雙支型號，滿足基礎測量或冗余備份需求。2519
服務支持
我們提供完善的技術咨詢和產品定制服務，可根據現場工況調整保護管材質、插深尺寸及安裝接口規格。產品出廠前經多道工序檢測，確保每臺設備在階躍溫度變化下的響應特性符合設計要求。對于特殊應用環境，可提供耐強酸強堿的增強型結構方案。所有產品均附帶詳細安裝指導手冊，協助用戶快速完成系統集成。101723
Product Introduction
The WZP-231 waterproof junction box is a temperature sensor housing designed for industrial applications, featuring fixed-thread connection and waterproof construction. It works with display instruments, recorders and electronic regulators to measure temperatures from -200°C to 420°C for liquids, vapors, gases and solid surfaces. The stainless steel housing provides mechanical durability and corrosion resistance, while the sealed junction box maintains reliable performance in dusty or humid environments.41114
Key Features
This product utilizes a double-sealed structure with labyrinth seals and fasteners to achieve dustproof/waterproof performance. The platinum RTD sensing element ensures fast thermal response (T0.5≤40S) and high measurement accuracy. Standard 12mm diameter protection tubes are available with customizable insertion depths (75-1200mm). The fixed-thread installation simplifies field deployment, and dual-element versions (WZP2-231) support simultaneous signal output for redundant monitoring systems. The design accommodates both 3-wire and 4-wire connection methods.51419
Technical Specifications
Technical highlights include: self-heating effect ≤0.30°C at 5mA; insulation resistance ≥100MΩ (10-100VDC); nominal pressure 6MPa (static, ambient). The platinum wire sensing element is uniformly wound on insulated frames for gradient measurement accuracy. Optional 304/316L stainless steel protection tubes address corrosive media. Compact design adapts to space-limited installations with customizable length/depth configurations. The waterproof terminal compartment withstands washdown conditions in food/pharmaceutical applications.111822
Typical Applications
Ideal for steam pipelines, chemical reactors, and food processing lines requiring splash resistance. Performs reliably in outdoor oil storage tanks, wharf pipelines exposed to rainwater, and pharmaceutical cleanrooms where sealing prevents contamination. The stainless steel construction withstands high-temperature media in boilers and synthesis towers. Single/Dual-element options serve basic measurement or redundant monitoring needs across industries including power generation, petrochemicals and HVAC systems.2523
Service Support
We offer technical consultation and custom solutions for special requirements including alternative materials, insertion lengths and mounting interfaces. All units undergo multi-stage testing to verify step-response characteristics. Enhanced versions are available for extreme acid/alkali environments. Detailed installation manuals accompany each product to facilitate system integration. Custom OEM configurations can be developed for large-volume applications.101723
防水式接線盒
WZP-270S, WRE-625, WZP-012S, K-250CD, WRP-100, WRE-010, WRE-220A, WRN-010, WRR2-010, WRN2-631, WZP2-010, WZP2-221, WZP2-220, WZP-231, WZP-230, WZP2-1312A, WZP2-106S, WRET2-31, WRN-235T, WRE-235T
編輯本段防水接線盒的材料
目前世界上生產標準防水接線盒的原材料主要有：ABS工程塑料、聚碳酸酯(PC)、PC/ABS、玻璃纖維增強聚酯、不銹鋼。根據不同的現場環境，用戶可以選擇滿足現場使用要求的材料。
ABS工程塑料：丙烯腈-丁二烯-苯乙烯共聚物（Acrylonitrile-Butadiene-Styrene，簡稱ABS)是一種通用型熱塑性聚合物，ABS性能特征：剛性好、沖擊強度高、耐熱、耐低溫、耐化學藥品性、機械強度和電器性能，易于加工，加工尺寸穩定性和表面光澤好，容易涂裝、著色，還可以進行噴涂金屬、電鍍、焊接和粘接等二次加工性能。由于ABS的特性結合了其三種組分的特點，使其具有的綜合性能，成為電器元件、家電、計算機和儀器儀表選的塑料之一。
聚碳酸酯(PC)材料：聚碳酸酯(簡稱PC)是分子鏈中含有碳酸酯基的高分子聚合物，根據酯基的結構可分為脂肪族、芳香族、脂肪族-芳香族等多種類型。其中由于脂肪族和脂肪族-芳香族聚碳酸酯的機械性能較低，從而限制了其在工程塑料方面的應用。目前僅有芳香族聚碳酸酯獲的了工業化生產。由于聚碳酸酯結構上的特殊性，現已成為五大工程塑料中增長速度快的通用工程塑料。
PC/ABS材料：聚碳酸酯和丙烯腈-丁二烯-苯乙烯共聚物和混合物，是由聚碳酸酯（Polycarbonate）和聚丙烯精（ABS）合金而成的熱可塑性塑膠，結合了兩種材料的優異特性，ABS材料的成型性和PC的機械性、沖擊強度和耐溫、抗紫外線（UV）等性質，可廣泛使用在汽車內部零件、事務機器、通信器材、家電用品及照明設備上。
防水接線盒的發展?fàn)顩r
國外發展?fàn)顩r：主要品牌有FIBOX、ENSTO、HENSEL、MECANO、RITTAL、HIBOX、HOFFMAN等品牌，產品類別各有不同。工程塑料類防水接線盒產品要以芬蘭FIBOX為主導。
國內發展?fàn)顩r：主要品牌有SRBOX、TIBOX、SAIP、無錫健龍等品牌，但目前國內防水接線盒產品質量性能差異較大，材料性能上差異也很大。目前在產品整體性能上外于先的是SRBOX產品，并且通過南德TUV標準認證和CE認證。
|
