電接點雙金屬溫度計 WZPK-124U 技術說明（中英對照）
【中文版】
產品概述：
WZPK-124U 型電接點雙金屬溫度計采用機械式溫度傳感技術，通過熱敏雙金屬片的熱膨脹原理實現溫度測量與控制功能。該產品適用于工業領域常規溫度監控場景，可對液體、氣體及蒸汽介質的溫度變化進行實時反饋。
核心優勢：
-
復合型結構設計
表頭與保護管采用316不銹鋼一體化成型工藝，具備抗振動、耐介質腐蝕特性。表殼內部配置密封墊圈，有效防止粉塵侵入和水汽凝結。
-
多點控制功能
內置可調式接觸點組件，支持用戶自定義設定上下限報警閾值。當被測介質溫度達到預設值時，觸點自動觸發開關信號，配合外部電路實現系統聯鎖控制。
-
可視化操作界面
270°廣角表盤配置高對比度刻度標識，標配熒光指針便于暗光環境讀取。通過表盤正面調節旋鈕可進行觸點位置校準，無需拆解設備即可完成參數調整。
技術參數：
- 測量范圍：-20℃～450℃（分段可選）
- 精度等級：±1.5% F.S
- 觸點容量：AC 220V/1A（阻性負載）
- 防護等級：IP54（防塵防濺水）
- 插入深度：50～500mm（客戶定制）
應用領域：
本產品適用于食品加工設備、化工管道系統、制藥機械等場景的溫度監控需求。典型應用包括反應釜過溫保護、蒸汽管道溫度聯鎖、熱交換設備工況監測等系統。
安裝維護：
提供軸向/徑向兩種安裝方向選擇，法蘭連接尺寸符合通用工業標準。建議每12個月進行觸點清潔保養，使用無水乙醇擦拭接觸點表面以確保信號傳輸可靠性。
【English Version】
Product Overview:
The WZPK-124U Bimetal Thermometer with Electrical Contact utilizes mechanical temperature sensing technology, achieving measurement and control functions through thermal expansion of bimetallic strips. This device is suitable for routine temperature monitoring in industrial environments, providing real-time feedback for liquid, gas and steam media.
Key Features:
-
Composite Structure Design
Stainless steel 316 monoblock construction for gauge head and protection tube ensures vibration resistance and media corrosion protection. Integrated sealing gaskets prevent dust ingress and moisture condensation.
-
Multi-point Control
Adjustable contact assembly allows customizable upper/lower alarm thresholds. Automatic switch signal activation occurs when temperature reaches preset values, enabling system interlocking through external circuits.
-
User-friendly Interface
270° dial with high-contrast scale markings and luminous pointer ensures readability in low-light conditions. Front-mounted calibration knob facilitates contact adjustment without disassembly.
Technical Specifications:
- Measuring Range: -20℃～450℃ (selectable segments)
- Accuracy: ±1.5% F.S
- Contact Rating: AC 220V/1A (resistive load)
- Protection: IP54 (dust/water splash proof)
- Immersion Depth: 50～500mm (customizable)
Applications:
Ideal for temperature monitoring in food processing equipment, chemical pipelines and pharmaceutical machinery. Typical applications include reactor overtemperature protection, steam pipeline interlocking and heat exchanger condition monitoring.
Installation & Maintenance:
Axial/radial mounting options with standardized flange dimensions. Recommended 12-month maintenance cycle includes contact cleaning using anhydrous ethanol to ensure signal transmission reliability.
