DH-SJ7 應變片特性及電子秤設計實驗儀【雙旭電子】對照
中文介紹
DH-SJ7 應變片特性及電子秤設計實驗儀是雙旭電子推出的一款實驗教學設備，旨在幫助學生深入理解應變片的工作原理及其在電子秤設計中的應用。該設備采用透明模塊化設計，將實驗元件插放于九孔板上，再置于整體機箱中，有效解決了實驗元件易損壞、不易管理的問題。
實驗內容豐富多樣，包括了解金屬箔式應變片的應變效應、電橋的工作原理，掌握單臂電橋、半橋、全橋的性能，并比較其靈敏度和非線性度。此外，學生還可以通過該設備自主設計電子秤系統，完成從理論到實踐的轉化。
在技術參數方面，該實驗儀配備了可調直流電壓源（0～12V連續可調，最大電流1A），以及多組對稱電源。電子秤傳感器的測量范圍為500g，內置4組350Ω應變片，能夠滿足基礎教學和實驗需求。此外，設備還提供了差動放大器模塊、電位器模塊、電阻模塊等多種實驗?zāi)K，方便學生進行多樣化的實驗設計。
English Introduction
The DH-SJ7 Strain Gauge Characteristics and Electronic Scale Design Experimental Instrument is an educational device introduced by Shuangxu Electronics, designed to help students gain a deep understanding of the working principles of strain gauges and their applications in electronic scale design. The device features a transparent modular design, with experimental components placed on a nine-hole board and then housed in a main case, effectively addressing issues of component fragility and management difficulties.
The experimental content is diverse, including understanding the strain effect of metal foil strain gauges and the working principles of Wheatstone bridges, as well as comparing the sensitivity and non-linearity of single-arm, half-bridge, and full-bridge configurations. Additionally, students can independently design an electronic scale system using this device, facilitating the transition from theory to practice.
In terms of technical specifications, the experimental instrument is equipped with an adjustable DC voltage source (0–12V continuously adjustable, with a maximum current of 1A) and multiple sets of symmetrical power supplies. The electronic scale sensor has a measurement range of 500g and includes four sets of 350Ω strain gauges, which can meet the basic requirements for teaching and experimentation. Moreover, the device provides various experimental modules, such as differential amplifier modules, potentiometer modules, and resistor modules, enabling students to design a wide range of experiments.
再置于整體機箱中，解決了實驗元件易損壞、不易管理的問題。各個型號包含了電學設計性、基本傳感器設計性、光電傳感器設計性、溫度傳感器設計性等實驗內容可以相互拓展，也可根據客戶需要單獨搭配，而且學生能夠自行拓展實驗內容，是本裝置的大特色，因此非常適合于物理基礎實驗教學。
基本傳感器型物理設計性實驗裝置采用分立的傳感器模塊及處理電路，主要由五部分組成：傳感器實驗臺、九孔板接口平臺、音頻振蕩器、直流恒壓源和處理電路模塊。
