角型電感式接近開關SN05-N3 供應
產品概述
角型電感式接近開關SN05-N3是一款基于電磁感應原理設計的高性能非接觸式檢測裝置，專為工業自動化場景中的金屬物體位置檢測而開發。其采用緊湊的方形結構設計，便于安裝與集成，適用于機械加工、物流分揀、設備安全防護等多種領域。該產品通過感應金屬物體靠近時產生的渦流變化實現快速響應，確保檢測過程穩定可靠。
SN05-N3具備優異的抗干擾能力和環境適應性，可在復雜工況下保持精準檢測。其內部采用優化的振蕩電路和信號處理技術，有效提升動作一致性，避免誤觸發。產品提供三線制接線方式（NPN/PNP可選），支持常開或常閉輸出模式，兼容主流PLC及控制系統的信號輸入需求。感應距離可達5mm，響應頻率為500Hz，滿足高速檢測場景的要求。
英文介紹（Overview）
The angular inductive proximity switch SN05-N3 is a high-performance non-contact detection device based on electromagnetic induction, designed for position sensing of metallic objects in industrial automation. Its compact rectangular housing facilitates easy installation and integration, making it suitable for applications such as machining, logistics sorting, and equipment safety protection.
By detecting eddy current changes generated when metal targets approach, the SN05-N3 ensures rapid response and stable operation. The product features enhanced anti-interference capabilities and environmental durability, maintaining accuracy even in challenging conditions. With an optimized oscillation circuit and signal processing technology, it delivers consistent actuation without false triggering.
The switch adopts a 3-wire connection (NPN/PNP configurable) and supports both normally open (NO) and normally closed (NC) output modes, compatible with most PLCs and control systems. Its sensing range reaches 5mm, and a response frequency of 500Hz meets high-speed detection requirements.
技術特點
SN05-N3采用全封閉式結構，外殼材質堅固耐腐蝕，防護等級達IP67，可抵御粉塵、油污及短時水浸影響。其工作電壓范圍覆蓋DC 10-30V，電壓波動容忍度達±15%，適應工業現場不穩定的電源環境。產品通過精密調校的感應線圈設計，確保對鐵、鋁、銅等多種金屬材質均具有穩定的檢測性能。
英文介紹（Features）
The SN05-N3 features a fully enclosed housing with robust and corrosion-resistant materials, achieving IP67 protection against dust, oil, and temporary water immersion. It operates within a wide voltage range of DC 10-30V, tolerating fluctuations up to ±15% to suit unstable power supply environments.
The precision-tuned sensing coil ensures stable detection performance for various metals including iron, aluminum, and copper. Its temperature stability allows operation in environments ranging from -25°C to +70°C, ensuring reliability in extreme conditions.
應用場景
該產品適用于自動化產線中的工件到位檢測、設備安全門狀態監控、流水線計數等場景。其非接觸式設計避免了機械磨損，顯著延長使用壽命。在包裝機械、汽車裝配、電子制造等領域，SN05-N3可精準觸發控制信號，提升生產效率和安全性。
英文介紹（Applications）
Ideal for automated production lines, the SN05-N3 is widely used in workpiece presence detection, safety door monitoring, and conveyor counting. Its non-contact design eliminates mechanical wear, significantly extending service life.
In packaging machinery, automotive assembly, and electronics manufacturing, the switch provides precise signal triggering to enhance productivity and operational safety. The compact size and versatile mounting options further simplify integration into space-constrained installations.
注：以上介紹避免使用極限化表述，聚焦產品功能與實際應用價值。15111326
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
