角型電感式接近開關SN05Y1 廠家
產品概述
角型電感式接近開關SN05Y1是一款采用電磁感應原理設計的高性能傳感器，專為工業自動化控制中的金屬物體檢測而開發。其獨特的角型結構便于在狹窄或復雜空間安裝，適用于機械定位、流水線計數等場景。該產品通過渦流效應實現非接觸式檢測，反應速度快且耐用性強，可在多種工業環境中穩定工作。18
技術特點
SN05Y1采用高頻振蕩器與信號放大電路一體化設計，檢測距離精準，重復定位精度高。外殼選用耐腐蝕材質，防護等級達到IP67，可抵御油污、粉塵及潮濕環境影響。輸出方式支持NPN/PNP三線制配置，兼容PLC等控制設備。內置LED狀態指示燈，便于現場調試與故障排查。產品工作電壓覆蓋DC6-36V寬范圍，適應不同電氣環境需求。21421
應用領域
適用于冶金、礦山機械、食品包裝、汽車制造等行業，可檢測各類金屬工件（如鐵、鋁、銅等）。典型應用包括沖床安全防護、傳送帶物料監控、旋轉設備速度檢測等。其緊湊的角型設計特別適合在安裝空間受限的場合使用，例如機床導軌側壁或自動化設備內部模塊。51120
產品優勢
相較于傳統機械開關，SN05Y1無物理接觸磨損，使用壽命顯著延長�？闺姶鸥蓴_能力強，在電機或變頻器附近仍能保持穩定信號輸出。溫度適應性廣，可在-25℃至+70℃環境中連續工作。提供插件式和出線式兩種接線方式，滿足不同現場布線需求。7915
Introduction
The angular inductive proximity switch SN05Y1 is a high-performance sensor based on electromagnetic induction principle, designed for metal object detection in industrial automation. Its angular housing facilitates installation in confined spaces, making it ideal for mechanical positioning and conveyor counting applications. Through eddy current effect, it achieves contactless detection with fast response and enhanced durability, ensuring reliable performance in diverse industrial environments.112
Key Features
Equipped with integrated high-frequency oscillator and signal amplification circuit, SN05Y1 delivers precise detection distance and high repeatability. The corrosion-resistant housing with IP67 protection resists oil, dust, and moisture. Compatible with NPN/PNP three-wire configurations, it seamlessly connects to PLC systems. Built-in LED status indicator simplifies on-site commissioning and troubleshooting. Wide operating voltage range (DC6-36V) adapts to various power conditions.21626
Applications
Widely used in metallurgy, mining machinery, packaging, and automotive manufacturing, SN05Y1 detects diverse metals (iron, aluminum, copper, etc.). Typical scenarios include punch press safety guarding, conveyor material monitoring, and rotary equipment speed measurement. The compact angular design is particularly suitable for space-constrained installations like machine tool rails or internal modules of automated equipment.52225
Benefits
Compared with mechanical switches, SN05Y1 eliminates physical wear through contactless operation, significantly extending service life. With strong EMI resistance, it maintains stable signal output near motors or frequency converters. Broad temperature tolerance (-25℃ to +70℃) ensures continuous operation in harsh conditions. Both connector and cable variants are available for flexible wiring solutions.71829
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
