角型電感式接近開關SN06-P2 價格
產品概述
角型電感式接近開關SN06-P2是一款高性能非接觸式檢測設備，采用電磁感應原理設計，專為工業自動化場景中金屬物體的精準檢測而開發。其緊湊的方形外殼結構（18×18×35mm）適合狹小空間安裝，背面配備LED工作狀態指示燈，當檢測到金屬物體時紅色LED亮起，操作直觀便捷。該產品通過LC高頻振蕩器產生交變磁場，當金屬目標進入感應區域時會引發渦流效應，從而觸發開關信號輸出，實現無接觸、無磨損的可靠檢測。188
核心特點
SN06-P2采用NPN晶體管集電極開路輸出模式，黑線作為信號輸出端可在檢測到物體時下拉至地電平，支持12-24V寬電壓輸入，驅動能力達100mA，可直接控制繼電器等負載。產品具有響應速度快（500Hz）、抗干擾能力強、防護等級達IP67等特點，能在油污、粉塵等惡劣工業環境中穩定工作。其檢測距離為1mm±10%，標準檢測體為鐵質材料，工作溫度范圍覆蓋-25℃至+85℃。獨特的非接觸式設計避免了機械磨損，使得產品壽命遠超傳統機械開關。1723
技術參數
• 電氣特性：直流三線制，工作電壓6-36VDC，輸出電流≤200mA
• 物理規格：角型外殼尺寸18×18×35mm，引線長度標準100mm（可定制）
• 環境適應性：環氧樹脂全密封結構，耐油污、抗震動，適應高頻機械動作場合
• 檢測性能：鐵質金屬標準檢測距離1mm±10%，響應時間≤1ms
• 輸出配置：NPN常開/常閉可選（SN06-P2為常開型），集電極開路輸出
產品采用耐沖擊ABS材質外殼，通過優化磁場分布設計實現穩定檢測性能，對不銹鋼、銅、鋁等常見金屬均有良好響應。內置反向極性保護和短路保護電路，確保設備安全運行。913
應用場景
SN06-P2廣泛應用于機床刀具定位、自動化生產線物料計數、機械手臂末端位置檢測等場景。在汽車制造領域用于零部件裝配到位檢測，在包裝機械中實現金屬包裝盒的通過檢測，在電梯控制系統里進行平層定位。其緊湊設計特別適合空間受限的安裝環境，如微型齒輪箱的轉速監測、AGV小車防撞檢測等。產品兼容PLC、單片機等控制系統，可通過外接1K電阻輕松轉換為電壓信號輸出模式。610
Product Introduction
The angular inductive proximity switch SN06-P2 is a high-performance non-contact detection device utilizing electromagnetic induction principle, specifically designed for precise metal object detection in industrial automation scenarios. Its compact rectangular housing (18×18×35mm) fits confined spaces, with a built-in LED status indicator that illuminates red when metal targets are detected, providing intuitive operation feedback. The LC oscillator generates alternating magnetic fields to induce eddy currents in metal objects, triggering reliable contactless switching without mechanical wear. 188
Key Features
Featuring NPN open-collector output configuration, the black wire serves as signal output that pulls to ground level upon detection, supporting 12-24V wide voltage range with 100mA drive capacity for direct relay control. With 500Hz response frequency, IP67 protection rating and anti-interference design, it operates stably in harsh environments containing oil, dust or vibrations. The 1mm±10% sensing distance (for iron) and -25℃ to +85℃ temperature range ensure reliable performance. Non-contact mechanism eliminates physical wear for extended service life. 1723
Specifications
• Electrical: 3-wire DC, 6-36VDC operating voltage, ≤200mA output current
• Mechanical: 18×18×35mm angular housing, standard 100mm cable (customizable)
• Environment: Epoxy encapsulated, resistant to oil and vibration for high-frequency operations
• Sensing: 1mm±10% detection for iron, ≤1ms response time
• Output: NPN NO/NC selectable (SN06-P2 default NO), open-collector output
The ABS housing with optimized magnetic field design ensures consistent detection of stainless steel, copper and aluminum. Integrated reverse polarity and short-circuit protection enhance operational safety. 913
Applications
Ideal for machine tool positioning, production line counting, and robotic arm end-effector detection. Used in automotive assembly for component presence verification, packaging machinery for metal container passage detection, and elevator control systems for leveling. Compact size suits space-constrained installations like micro gearbox speed monitoring and AGV collision avoidance. Compatible with PLCs and microcontrollers, easily converts to voltage signal output via external 1K resistor. 610
角型電感式接近開關
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近開關，磁性開關,被廣泛應用于各種機械、機床制造業及紡織、造紙、煙草、輕工、食品、化工、礦山、冶金、航空工業、電力保安、汽車工業、船舶交通運輸、建筑、地等各行各業，作限位、定位檢測，自動計數，測速，自動保護，工業生產自動流水線及微機信號，數控裝置等應用.詳細技術資料請到公司網站查詢 .FJ13-25KA
FJ13 安裝方式埋入式非埋入式檢測距離 25mm 交流AC90-250V二線制NO 常開 FJ13-M25KA NC 常閉 FJ13-M25KB 三線制NO+NC 常開常閉 FJ13-M25KE 繼電輸出四線NO+NC 常開常閉 FJ13-M25JC 繼電輸出五線NO+NC 常開常閉 直流DC6-36VNPNNO 常開 FJ13-M25NA NC 常閉 FJ13-M25NB NO+NC 常開常閉 FJ13-M25NC PNPNO 常開 FJ13-M25PA NC 常閉 FJ13-M25PB NO+NC 常開常閉 FJ13-M25PC 二線制NO 常開 FJ13-M25LA NC 常閉 FJ13-M25LB 輸出電壓降DC/ACAC 輸出電流可控硅SCR 300mA 繼電器1A、2A DC三線200mA DC二線 50mA重復精度 消耗電流 響應頻率DC 300Hz,AC 10Hz 外殼體材料塑料ABS設定距離0-20mm 標準檢測物體60 x 60 x 1（鐵）工作環境溫度-20℃~+55℃連接方式1.5m PVC電纜防護等級IP67
|
