產品概述
ZD-500L全自動電容電感測試儀是一款專為電力系統設計的智能化測量設備，主要用于現場快速測量并聯電容器組中的單個電容器電容值以及電抗器電感量。該產品采用大屏幕液晶顯示（320×240LCD），支持漢字菜單操作提示，實現波形與測量數據同屏顯示，使測試過程更加直觀高效。其設計解決了傳統測量中需拆除連接線、工作量大且易損壞電容器的問題，同時提高了故障檢出率。16
核心功能特點
該儀器具備自動量程轉換功能，可存儲7168組測試數據，支持波形與數據處理同步顯示。測試電壓范圍覆蓋AC 2V至30V，可根據試品阻抗智能選擇電壓檔位。采用鉗形CT電流檢測技術，可直接夾取電容引線或電壓線進行非接觸式測量，并自動識別電容、電感或電阻屬性。特別設計的抗干擾方案使鉗形CT可遠離儀器1米以上，有效避免磁場干擾。此外，其電流測量單元還可兼容CVT、避雷器等設備的測試需求，實現一機多用。121
技術參數與測量范圍
電容測量范圍覆蓋0.2μF至2200μF，分為三個量程段，精度達±(1%讀數+0.1%滿度)；電感測量范圍50mH至5H，精度±(3%讀數+0.2%滿度)。電流測量支持0.1A-20A寬范圍，精度±(1%讀數+5個字)。儀器采用AC220V供電，輸出試驗電壓為交流23V±10%（電容模式）或3V±20%（電感模式），最大輸出電流20A，適應各類現場環境。112
應用場景與優勢
本產品特別適用于變電站無功補償裝置的維護檢測，無需拆除母線即可完成單相或三相電容器的快速測量，顯著提升工作效率。其高精度數字合成技術避免了電源電壓波動的影響，全自動測量流程消除了人工操作誤差。人性化設計包括面板式熱敏打印機、370×370×220mm緊湊機身及16kg輕量化結構，便于現場攜帶與操作。723
Product Introduction
The ZD-500L Automatic Capacitance and Inductance Tester is an intelligent measurement device designed for power systems, specializing in on-site rapid testing of individual capacitor values in parallel capacitor banks and reactor inductance. Featuring a large LCD screen (320×240) with Chinese menu guidance, it simultaneously displays waveforms and measurement data for intuitive operation. This design eliminates the need for disconnecting wires during traditional measurements, significantly reducing workload and equipment damage risks while improving fault detection accuracy.621
Key Features
With auto-ranging capability and 7168 data storage capacity, the tester supports synchronous waveform and data analysis. Its testing voltage ranges from AC 2V to 30V with intelligent voltage selection based on impedance. The clamp-type CT current detection allows non-contact measurement by directly clamping capacitor leads or voltage wires, automatically identifying capacitor, inductor, or resistor properties. The anti-interference design enables the CT to operate over 1 meter away from the instrument. Additionally, its current measurement unit can be used for CVT and arrester testing, achieving multi-functional applications.112
Technical Specifications
Capacitance measurement covers 0.2μF-2200μF across three ranges with ±(1% reading +0.1% full scale) accuracy, while inductance measurement spans 50mH-5H with ±(3% reading +0.2% full scale) accuracy. Current measurement supports 0.1A-20A range at ±(1% reading +5 digits) precision. Powered by AC220V, it outputs AC 23V±10% (capacitance mode) or 3V±20% (inductance mode) test voltage with 20A max current, suitable for various field conditions.723
Applications
Ideal for maintaining reactive power compensation devices in substations, this tester enables three-phase capacitor measurement without busbar disassembly, dramatically improving efficiency. Its digital synthesis technology eliminates power voltage fluctuation impacts, and fully automated processes remove manual errors. User-friendly designs include a built-in thermal printer, compact 370×370×220mm dimensions and 16kg lightweight structure for easy portability.121
