XTD-LS系列拉繩開關產品介紹（中英對照）
一、產品概述
XTD-LS系列拉繩開關是針對工業環境設計的緊急停機控制裝置，采用模塊化結構設計，適用于各類皮帶輸送機、生產線設備及自動化系統的安全防護。產品通過機械觸發原理實現快速響應，在設備運行異常時提供即時保護，有效降低意外事故風險，保障作業人員與設備安全。
二、核心優勢
- 穩定運行機制：優化機械傳動結構，動作行程精確可控，有效避免誤觸發現象。雙觸點冗余設計提升信號傳輸可靠性，適應復雜工況環境。
- 長效耐用配置：外殼采用高強度工程塑料注塑成型，內部精密金屬部件經多層防腐處理，耐受-30℃至+80℃溫度范圍及粉塵、潮濕等惡劣環境考驗。
- 靈活適配方案：提供多角度安裝支架與調節組件，支持水平/垂直多向安裝。電纜接口標配防水鎖緊裝置，可選配不同線纜長度（標準配置3米）。
- 維護便捷設計：模塊化組件支持快速拆裝維護，透明觀察窗設計便于狀態監測，復位機構實現一鍵式恢復操作。
三、典型應用領域
• 礦山開采運輸系統緊急制動
• 港口碼頭輸送帶安全防護
• 化工生產線緊急停機控制
• 糧食倉儲自動化保護裝置
• 包裝機械安全聯鎖系統
四、技術參數
動作行程：20±2mm
復位力：≤45N
觸點容量：AC 250V/5A
防護等級：IP67
機械壽命：＞100萬次
工作電壓范圍：24-380V AC/DC
環境濕度：≤95% RH（無凝露）
五、服務支持
提供專業技術咨詢選型服務，根據具體應用場景推薦適配解決方案。產品出廠前經過嚴格質量檢測，配備詳細操作手冊及安裝示意圖。支持定制化服務，包括特殊尺寸、接線方式及外觀配色調整。
XTD-LS Series Emergency Pull Cord Switch Product Introduction
I. Product Overview
The XTD-LS series emergency pull cord switch is an industrial-grade safety device designed for emergency shutdown applications. Featuring modular construction, it provides reliable protection for belt conveyors, production lines, and automated systems. Utilizing mechanical triggering mechanism, the device ensures instant response to abnormal equipment operation, effectively reducing accident risks and safeguarding both personnel and machinery.
II. Key Features
- Reliable Operation: Precision-engineered transmission mechanism with adjustable actuation stroke minimizes false triggering. Dual-contact redundancy design enhances signal stability in harsh environments.
- Robust Construction: Impact-resistant engineering plastic housing with corrosion-proof internal components withstands temperature extremes (-30℃ to +80℃) and challenging conditions including dust and moisture.
- Flexible Installation: Multi-directional mounting brackets with adjustable angles accommodate various spatial requirements. Waterproof cable glands come as standard, with optional cable lengths (3m standard).
- Maintenance-Friendly: Modular components enable quick disassembly, transparent inspection window allows visual status check, and manual reset function simplifies reactivation.
III. Application Scenarios
√ Emergency braking for mining conveyor systems
√ Safety protection in port logistics operations
√ Process line emergency stop control
√ Automated protection in grain storage
√ Safety interlock for packaging machinery
IV. Technical Specifications
Actuation Travel: 20±2mm
Reset Force: ≤45N
Contact Rating: AC 250V/5A
Ingress Protection: IP67
Mechanical Life: >1 million cycles
Voltage Range: 24-380V AC/DC
Ambient Humidity: ≤95% RH (non-condensing)
V. Service Support
Professional technical consultation for product selection and application-specific solutions. Each unit undergoes rigorous quality inspection prior to shipment, accompanied by detailed operation manual and installation guide. Customization services available for special dimensions, wiring configurations, and color schemes.
