跑偏開關DPK-12-30 供應
DPK-12-30跑偏開關產品介紹
一、產品概述
DPK - 12 - 30跑偏開關是一種用于輸送帶系統中的重要安全保護裝置。它通過檢測輸送帶的跑偏情況，及時發出信號，從而有效避免輸送帶因過度跑偏而引發的設備損壞、物料撒漏以及生產中斷等一系列問題，廣泛應用于礦山、港口、電廠、水泥廠等眾多輸送物料的工業場景。
二、產品特點
（一）高靈敏度
該跑偏開關能夠精準感知輸送帶的微小偏移。其內部采用先進的傳感器技術，當輸送帶偏離正常位置達到設定角度時，開關迅速響應，確保在跑偏初期就能及時發現并采取措施，大大提高了輸送系統的安全性和可靠性。
（二）耐用性強
在惡劣的工業環境下，DPK - 12 - 30跑偏開關展現出卓越的耐用性能。外殼采用高強度材料制造，具備良好的抗沖擊性和耐腐蝕性，能夠抵御粉塵、潮濕以及各種化學物質的侵蝕，延長使用壽命，降低設備維護成本。
（三）安裝便捷
其設計充分考慮了用戶的安裝需求。結構緊湊，安裝方式靈活多樣，無論是水平安裝還是垂直安裝，都能輕松實現。同時，配備清晰的安裝說明和簡單的連接方式，用戶無需專業技能即可快速完成安裝，節省時間和人力成本。
三、工作原理
當輸送帶發生跑偏時，輸送帶會觸碰到跑偏開關的擺臂。擺臂在受到外力作用后，會帶動內部的微動開關動作，從而改變電路狀態，發出報警信號或切斷電源，使輸送機停止運行。這種機械與電氣相結合的工作方式，反應迅速且穩定可靠，為輸送系統的安全運行提供了有力保障。
四、應用優勢
使用DPK - 12 - 30跑偏開關，可以有效減少因輸送帶跑偏造成的設備維修次數和維修成本。同時，它能夠保障生產過程的連續性，避免因設備故障導致的生產延誤，提高生產效率。此外，該跑偏開關還能有效防止物料因輸送帶跑偏而撒漏，減少物料浪費，降低清理成本，為企業的可持續發展提供支持。
DPK - 12 - 30跑偏開關憑借其卓越的性能和廣泛的應用優勢，是輸送系統中不可或缺的安全保護裝置，為工業生產的安全、高效運行保駕護航。
Introduction of DPK - 12 - 30 Belt Misalignment Switch
I. Product Overview
The DPK - 12 - 30 belt misalignment switch is a vital safety protection device in conveyor belt systems. It detects the misalignment of the conveyor belt and promptly sends out signals to effectively prevent a range of issues such as equipment damage, material spillage, and production interruptions caused by excessive belt misalignment. It is widely used in various industrial settings for material conveying, including mines, ports, power plants, cement plants, and more.
II. Product Features
(i) High Sensitivity
This misalignment switch can accurately detect even minor deviations of the conveyor belt. Equipped with advanced sensor technology, it responds swiftly when the belt deviates from its normal position by a set angle. This ensures that belt misalignment is detected and addressed in its early stages, significantly enhancing the safety and reliability of the conveying system.
(ii) Durability
In harsh industrial environments, the DPK - 12 - 30 belt misalignment switch demonstrates excellent durability. The housing is made of high - strength materials, offering good resistance to impact and corrosion. It can withstand erosion from dust, moisture, and various chemicals, extending the service life of the device and reducing maintenance costs.
(iii) Easy Installation
The design of this switch takes user - friendly installation into account. It has a compact structure and offers flexible installation options, whether for horizontal or vertical mounting. It also comes with clear installation instructions and simple connection methods, allowing users to complete the installation quickly without specialized skills, saving time and labor costs.
III. Working Principle
When the conveyor belt misaligns, it comes into contact with the arm of the misalignment switch. The arm, under the influence of the external force, triggers the internal micro - switch, altering the electrical circuit state and sending out an alarm signal or cutting off the power to stop the conveyor. This combination of mechanical and electrical working principles ensures a rapid and stable response, providing reliable protection for the safe operation of the conveying system.
IV. Application Advantages
Using the DPK - 12 - 30 belt misalignment switch can significantly reduce the number of equipment repairs and maintenance costs caused by belt misalignment. It also ensures the continuity of the production process, avoiding production delays due to equipment failures and improving production efficiency. In addition, this switch helps prevent material spillage from belt misalignment, reducing material waste and cleaning costs, and supporting the sustainable development of enterprises.
The DPK - 12 - 30 belt misalignment switch, with its outstanding performance and extensive application advantages, is an essential safety protection device in conveying systems, safeguarding the safe and efficient operation of industrial production.
跑偏開關
LW-PKG-12-30，PK1-2BW，PXA-34K，PXA-34KK-A，PH12-30，ROS-2D，TLPK，WHKP-12-30，XLPP，YTJKPT1，YTJKPT2，YWPPH，ZWQ-I2-30， DDP-LJ2， DPK-12-30，DPP-LJ2, HFKPT1-12-30，HFKPT1-20-35，
工作原理
跑偏開關固定在輸送機皮帶支架上，動作桿靠在皮帶一側，當皮帶跑偏時，迫使動作桿偏離，觸動報警微動開關。如果繼續偏離，觸動另一組觸點，輸送機就會保護性停機。
主要技術數據
輸出觸點：兩組SPDT，10A/500V；
動作角度：第10度，第二級20度；
作用力：3-4kg；
動作桿距皮帶邊緣安裝距離：25-75mm；
出線接口螺紋：3/4″NPT，兩個；
防護等級：IP65，適合室外安裝。
跑偏開關（Belt Sway Switches）又稱防偏開關，也叫兩級跑偏開關。用于檢測帶式輸送機運行中的跑偏現象，按皮帶實際跑偏量輸出報警或停機信號，可有效的防止由皮帶跑偏而產生的事故，是一種帶式輸送機的保護裝置。
安裝和調整
1.跑偏開關設在輸送帶兩側，立輥應與輸送帶邊平面垂直，并使輸送帶兩邊位于立輥高度1/3處。
2.跑偏開關立輥與輸送帶正常位置的間距宜為50～100mm。
3.跑偏開關數量應根據輸送機長度、類型及布置情況進行確定。一般應在輸送機頭部、尾部、凸弧段、凹弧段和在輸送機中間位置進行設置。（注：當輸送機較長時，在輸送機中間位置可每隔30～35米設1對）
4.跑偏開關應通過安裝支架與輸送機中間架連接，開關支架應在輸送機安裝完成后與輸送機機架焊接，跑偏開關與跑偏開關支架用螺栓固定。
適用范圍
兩級跑偏開關廣泛用于冶金、煤炭、水泥建材、采礦、電力、港埠、冶金、化工等域的各種帶式輸送設備。
|
