WZPK-274S鉑電阻溫度傳感器產品介紹
WZPK-274S鉑電阻溫度傳感器是一款專為工業溫度測量設計的精密測溫元件，采用高純度鉑絲作為核心感溫材料，結合優化的結構設計，可廣泛應用于暖通空調、食品加工、制藥設備、化工反應裝置等領域的溫度監控場景。產品通過科學的熱響應優化設計，能夠在復雜工況下實現穩定可靠的數據傳輸，為工藝流程控制提供精準的溫度反饋。
該型號傳感器采用316L不銹鋼材質護套，兼具優異的機械強度和耐腐蝕性能，可長期耐受高溫高壓環境。內部填充高純度氧化鎂絕緣材料，有效提升元件抗震性和熱傳導效率。感溫元件與保護管采用全密封焊接工藝，防護等級達IP65，有效防止水汽、粉塵侵入。產品提供多種安裝接口選擇，支持M12×1.5、M16×1.5等標準螺紋規格，同時可定制法蘭安裝方式，便于不同設備結構的集成安裝。
在技術參數方面，測溫范圍覆蓋-50℃至+300℃區間，滿足大部分工業場景需求。元件采用三線制接線方式，有效降低導線電阻對測量精度的影響。導線標配耐高溫氟塑絕緣層，可耐受200℃環境溫度持續工作。產品經過嚴格的老化篩選測試，在-20℃至+150℃工作環境下年漂移量小于0.1℃，確保長期測量穩定性。特殊設計的錐形探頭結構顯著提升介質接觸效率，典型熱響應時間τ0.5≤8秒（液體介質中）。
針對特殊應用需求，本產品可提供防爆型結構設計，探頭長度可在50mm至1000mm范圍內定制，導線長度支持最長20米延伸。產品嚴格執行質量管理體系，出廠前逐支進行多點溫度標定，確保每支傳感器交付時均達到標稱精度要求。
WZPK-274S Platinum Resistance Temperature Detector Product Introduction
The WZPK-274S Platinum Resistance Temperature Detector is a precision temperature measurement component specifically designed for industrial applications. Utilizing high-purity platinum wire as the core sensing element and optimized structural design, it is widely applicable for temperature monitoring in HVAC systems, food processing equipment, pharmaceutical manufacturing facilities, and chemical reaction vessels. Through scientifically optimized thermal response characteristics, the product ensures stable and reliable data transmission in complex working conditions, providing accurate temperature feedback for process control.
Featuring a 316L stainless steel protective sheath, this sensor demonstrates exceptional mechanical strength and corrosion resistance, capable of withstanding prolonged exposure to high-temperature and high-pressure environments. The internal high-purity magnesium oxide insulation effectively enhances vibration resistance and thermal conductivity. The fully welded hermetic sealing process achieves IP65 protection rating, effectively preventing moisture and dust ingress. Multiple installation interfaces are available, including standard threaded specifications such as M12×1.5 and M16×1.5, with optional flange mounting configurations for flexible integration with various equipment structures.
Technical specifications include a temperature measurement range from -50℃ to +300℃, suitable for most industrial requirements. The three-wire connection system significantly reduces the impact of lead resistance on measurement accuracy. Standard high-temperature fluoropolymer insulated cables can withstand continuous operation in 200℃ environments. Rigorous aging screening tests ensure long-term stability with annual drift less than 0.1℃ in operating temperatures between -20℃ and +150℃. The specially designed tapered probe structure improves medium contact efficiency, achieving typical thermal response time τ0.5≤8 seconds in liquid media.
For specialized applications, explosion-proof configurations are available. Customization options include probe lengths ranging from 50mm to 1000mm and extension cables up to 20 meters. Each unit undergoes multi-point temperature calibration prior to delivery to ensure compliance with specified accuracy requirements, supported by comprehensive quality management protocols throughout the manufacturing process.
