電站測溫用熱電阻WZP2-230B 廠家
中文介紹
WZP2-230B型熱電阻是一種高性能的溫度測量傳感器，廣泛應用于電站等工業領域的溫度監測。該產品采用雙支鉑熱電阻設計，能夠同時為兩套顯示、記錄或調節儀器提供溫度數據，滿足多設備同時測量的需求。其測溫范圍為-200℃至500℃，能夠適應電站等復雜環境下的各種溫度測量需求。
該熱電阻的感溫元件采用鉑絲繞組，具有良好的線性特性，測量精度高。其分度號為Pt100，B級精度的允許偏差為±（0.3℃+0.005|t|），能夠滿足電站等工業場景對溫度測量精度的要求。產品采用防水式接線盒設計，保護管材質為不銹鋼，具有良好的耐腐蝕性和機械強度，能夠有效抵御電站環境中的潮濕和腐蝕。
此外，WZP2-230B熱電阻的裝配簡單，更換方便，壓簧式感溫元件設計使其抗振性能良好，能夠在電站等振動較大的環境中穩定工作。其熱響應時間短，能夠快速響應溫度變化，及時為設備提供準確的溫度信息。
English Introduction
The WZP2-230B thermoresistor is a high-performance temperature measurement sensor widely used for temperature monitoring in power plants and other industrial applications. This product features a dual platinum thermoresistor design, capable of providing temperature data to two sets of display, recording, or control instruments simultaneously, meeting the needs of multiple devices for temperature measurement. Its temperature measurement range is from -200℃ to 500℃, which can meet the temperature measurement requirements in various complex environments of power plants.
The temperature-sensing element of the WZP2-230B thermoresistor is made of a platinum wire winding, which has good linear characteristics and high measurement accuracy. With a Pt100 scale, the allowable deviation of the B-grade precision is ±(0.3℃+0.005|t|), which can meet the requirements of power plants and other industrial scenarios for temperature measurement accuracy. The product adopts a waterproof junction box design, and the protection tube is made of stainless steel, which has good corrosion resistance and mechanical strength, and can effectively resist humidity and corrosion in the power plant environment.
In addition, the WZP2-230B thermoresistor is easy to assemble and replace, and the spring-loaded temperature-sensing element design makes it have good anti-vibration performance, which can work stably in environments with large vibrations such as power plants. Its fast thermal response time allows it to quickly respond to temperature changes and provide accurate temperature information to equipment in a timely manner.
電站測溫用熱電阻
WZC-130B，WZP-220B，WZP-221B，WZP-230B，WZP-231B，WZP2-220B，WZP2-221B，WZP2-230B，WZP2-231B，WZP-220AB，WZP2-220AB。WZC-220B，WZC-230B，WZC-220AB，WZP-320B，WZP-321B，WZP-330B，WZP-331B，WZP2-320B，WZP2-321B，WZP2-330B，WZP2-330B，WZC-320B，WZC-320B，WZP-420B，WZP-421B，WZP-430B，WZP-431B，WZP2-420B，WZP2-421B，WZP2-430B，WZP2-431B，WZP-42AB，WZP2-42AB，WZC-420B，WZC-430B，WZP-420B，WZP-421B，WZP-430B，WZP-430B，WZP-431B，WZP2-420B，WZP2-421B，WZP2-430B，WZP2-431B，WZP-42AB，WZP2-42AB，WZP-420B，WZC-430B，WZP-621B，WZP-621AB，WZP-631B，WZP2 -621B，WZP2 -621B，WZP2 -631B，WZP-621B，WZP-631B，WZP-621B，WZP2 -631B，WZP-621AB，WZP2-621AB，WZP-002，WZP-003，WZP-003A，WZCM-201，WZPM-201，WZPM-201，WZP-270S，WZP-26S，WZP-236SB，
量程規格
名 稱 分度號 測溫范圍 ℃ 精度等級 允 差Δt
鎳鉻－鎳硅熱電偶 K 0～800 2 ±2.5℃或 ±0.75％t
鎳鉻－銅鎳熱電偶 E 0～600 2 ±2.5℃或 ±0.75％t
鉑熱電阻 Pt100 -200～500 B ±（0.3＋0.005|t|）
注：t為感溫元件實測溫度或?qū)崪y溫度的值。
□公稱壓力
一般是指在常溫下，保護管所能承受的靜態外壓而不破裂，試驗壓力一般采用公稱壓力的1.5倍。實際上，允許工作壓力不僅與保護管材料、直徑、壁厚有關，而且還與其結構形式、安裝方法、置入深度以及被測介質的流速、種類有關。
□熱電偶絕緣電阻
常溫絕緣電阻的試驗電壓為直流500Ｖ。測量常溫絕緣電阻的大氣條件為：溫度15～35℃，相對濕度45％RH，大氣壓力86～106kPa。
對于長度超過1米的熱電偶，它的常溫絕緣電阻值與其長度的乘積應不小于100MΩ•m，
即：Rr•L＞100MΩ•mL＞1m
式中：Rr-熱電偶的常溫絕緣電阻值，MΩ；
L－熱電偶的長度，m。
對于長度等于或不足1米的熱電偶，它的常溫絕緣電阻值應不小于100MΩ。
□熱電阻絕緣電阻
常溫絕緣電阻的試驗電壓可取直流10～100Ｖ任意值，環境溫度應在15～35℃范圍內，相對濕度應不大于80％RH，常溫絕緣電阻值應不小于100MΩ。
□熱電阻允許通過電流
通過鉑電阻的測量電流大不超過5mＡ。
|
