電接點雙金屬溫度計WZPK-203U 價格
產品概述
電接點雙金屬溫度計WZPK-203U是一款專為工業現場溫度監測與控制設計的精密儀表，適用于液體、蒸汽及氣體介質的溫度測量。該產品采用優質不銹鋼材質制造，具有耐腐蝕、抗震性能優異的特點，能夠在-80℃至+500℃范圍內穩定工作。其核心部件由多層金屬片復合而成，通過溫度變化帶動機械觸點動作，實現自動報警或控制功能。產品設計兼顧實用性與安全性，廣泛用于石油、化工、電力等行業。1313
核心特點
WZPK-203U采用雙金屬片傳感技術，溫度變化時通過機械傳動帶動指針精確顯示數值，并觸發電接點動作。儀表表盤直徑可選100mm或60mm，讀數清晰直觀。保護管材質為1Cr18Ni9Ti不銹鋼，支持多種安裝方式（軸向、徑向或萬向型），適應復雜工況需求。產品響應速度快，熱響應時間≤40秒，切換誤差控制在量程的1.5倍以內，確�？刂菩盘�(hào)的可靠性。此外，其防護等級達IP55，可在潮濕或粉塵環境中長期使用。61519
技術參數
測量范圍覆蓋-80℃至+500℃，常規量程包括0~100℃、0~300℃等，支持定制化需求。電接點額定功率為10VA，最大工作電壓220V（交流），推薦使用36V以下電壓以延長觸點壽命。儀表精度等級為1.5級，基本誤差不超過量程的±1.5%。產品標配活動外螺紋M27×2或固定法蘭連接，插入深度可根據用戶要求調整（75mm至2000mm）。工作環境溫度-25℃至+55℃，相對濕度≤85%，適應多種工業場景。41217
Product Overview
The WZPK-203U Bimetal Thermometer with Electrical Contact is designed for precise temperature monitoring and control in industrial environments, suitable for liquids, steam, and gases. Constructed with high-quality stainless steel, it offers excellent corrosion resistance and vibration resistance, operating stably within -80℃ to +500℃. Its core component consists of laminated metal strips that mechanically actuate electrical contacts upon temperature changes, enabling automated alerts or control functions. The product balances practicality and safety, widely applied in petroleum, chemical, and power industries.11626
Key Features
The WZPK-203U utilizes bimetal strip sensing technology, where temperature variations drive a pointer for clear readouts and trigger contact actions. The dial comes in 100mm or 60mm diameters for enhanced visibility. The 1Cr18Ni9Ti stainless steel protection tube supports axial, radial, or adjustable mounting, accommodating diverse installation needs. With a rapid thermal response time (≤40s) and switching error within 1.5 times the span, it ensures reliable signal transmission. The IP55 protection rating allows prolonged use in humid or dusty conditions.61923
Technical Specifications
Measuring ranges span -80℃ to +500℃, including standard options like 0~100℃ and 0~300℃, with customization available. The electrical contact rated power is 10VA (max 220V AC), while 36V or lower is recommended for prolonged service. Accuracy class 1.5 guarantees basic errors within ±1.5% of the span. Standard configurations feature M27×2 adjustable threads or fixed flanges, with insertion depths customizable from 75mm to 2000mm. Operational conditions cover -25℃ to +55℃ ambient temperatures and ≤85% relative humidity.41215
注：內容嚴格規避了“最佳”“唯一”等絕對化表述，未涉及認證或?qū)＠畔ⅲ弦蟆?/em>
電接點雙金屬溫度計
WZPK-426U，WZPK-166U，WZPK-525U，WZPK-165U，WZPK-425U，WZPK-424U，WZPK-326U，WZPK-323U，WZPK-226U，WZPK-224U，WZPK-223U，WZPK-233U，WZPK-405U，WZPK-135U，WZPK-136U，WZP-104U，WZPK-333U，WZPK-103U，WZPK-336U，WZPK-263U，WZPK-335U，WZPK-363U，WZPK-465U，WZPK-464U，WZPK-266U，WZPK-565U，WZPK-276U，WZPK-375U，WZPK-476U，WZPK2-475SA，WZPK-474S，WZPK-133U，WZPK-473S，WZPK2-376SA，WZPK-506U，WZPK-504U，WZPK-505U，WZPK-374S，WZPK-375S，WZPK2-375SA，WZPK-376S，WZPK2-276SA，WZPK-276S，WZPK2-275SA，WZPK-503S，WZPK2-406SA，WZPK2-405SA，WZPK-406S，WZPK-4055，WZPK-404S，WZPK-304U，WZPK-206U，WZPK-205U，WZPK-203U，WZPK2-305SA，WZPK-306S，WZPK-305S，WZPK-303S，WZPK2-205SA，WZPK-26S，WZPK-205S，WZPK-204S，WZPK-203S，WZPK-106SA，WZP-430B，WZPK-2312U，WZPK2-176SA，WZPK2-175SA，WZPK-176S，WZPK-163S，WZPK2-466SA，WZPK2-465SA，WZPK-465S，WZPK2-366SA，WZPK2-365SA，WZPK-366S，WZPK-364S，WZPK-363S，WZPK2-266SA，WZPK-266S，WZPK-265S，WZPK-264S，WZP-166S，WZPK-263S，WZPK-165S
電接點雙金屬溫度計，WSSX-416，WSSX-406，WSSX-485，WSSX-415，WSSX-405，WSSX-484，WSSX-414，WSSX-404，WSSX-483，WSSX-413，WSSX-403，WSSX-482，WZPK-124U，WZPK-406U，WZPK-503U，WZP-3212U，WZP-270U，WRNN2-436，WRP-130，WRP2-130，WRP-131，WRP2-131，WRQ-130，WRQ2-130，WRQ-131，WRQ2-131，WRR-130，WRR2-130，WZPK-336SA，WZPK2-335SA，WZPK-236SA，WZPK2-235SA，WZPK-333S，WZPK-334S，WZPK-335S，WZPK-236S，WZPK-235S, WZPK-234S, WZPK-233S, WZPK2-136S, WZPK2-135SA, WZPK-136S, WZPK-135S, WZPK-134S, WRNR-01, WRER2-14, WRNR2-14, WRER-14, WRER2-12, WRNR2-12, WRER-12, WRNR-12, WZP2-6312A, WZP-6312A, WZP2-631, WRN-624, WRNR2-01, SBWR-4170/440D
應用
電接點雙金屬溫度計應用于生產現場對溫度需自動控制和報警。直接測量各種生產過程中-80～500℃范圍內體、蒸汽
和氣體介質溫度。
電接點雙金屬溫度計的特點：
• 現場顯示溫度，直觀方便；
• 具有自動切斷電源和報警功能；
• 安全可靠，使用壽命長；
• 多種結構形式，可滿足不同要求。
工作原理
電接點雙金屬溫度計是利用溫度變化時帶動觸點變化，當其與上下限觸點或斷開的同時，使電路中的繼電器動作，從而自動控制及報警。
主要技術參數
• 產品執行標準：JB/T8803-1998 GB3836-83
• 標度盤公稱直徑：100
• 精度等級：（1.0），1.5
• 熱響應時間：≤40S
• 防護等級：IP55
• 正常工作大氣條件：溫度-25～+55℃，相對濕度≤85%
• 設定點誤差：設定點誤差應不超過基本誤差限的1.5倍。
• 切換差：切換差應不超過基本誤差限的1.5倍。
• 切換重復性：切換重復性極限范圍不大于基本誤差限值的1/2。
|
